BMW 3 Series Sedan (G20), technical data

THE 3

THE BMW 3 SERIES SEDAN: ENGINES & TECHNICAL DATA

Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 3 Series Sedan.

Read more
THE 3THE BMW 3 SERIES SEDAN: ENGINES & TECHNICAL DATA

TECHNICAL DATA OF THE BMW 3 SERIES

Select model

Weight

Unladen weight EU in kg 1,570
Max. permissible weight in kg 2,050
Permitted load in kg 555
Permitted axle load front/rear in kg 965/1,150
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 235
Acceleration 0–100 km/h in s 7.1
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 7.4
Extra-urban in l/100 km 5.6
Combined in l/100 km 6.3
CO2 combined emissions in g/km 144
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 205/60 R16 96 W XL
Tyre dimensions rear 205/60 R16 96 W XL
Wheel dimensions and material front 6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear 6.5 J x 16 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,580-1,545
Max. permissible weight in kg 2,060
Permitted load in kg 555-590
Permitted axle load front/rear in kg 985/1,160
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 190 (258)/5,000-6,500
Engine torque (Nm) at 1/min 400/1,550-4,400
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.9-5.8
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 7.9
Extra-urban in l/100 km 5.8
Combined in l/100 km 6.6
CO2 combined emissions in g/km 150
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW 330i Sedan:
Fuel consumption in l/100 km (combined): 7.3–6.4
CO2 emissions in g/km (combined): 166–147



Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

Read more
​

Fuel consumption and CO2 emissions.

  • Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp.

    All technical data are indicative only and varies as per market and configuration. For more information, please check with your local dealer for all fuel consumption and CO2 emissions.
